| Parameter | Specification |
|---|---|
| Capacity | 1 KVA to 50 KVA |
| Input Voltage | 190–280V / 170–270V / 140-270V |
| Output Voltage | 220V / 230V / 240V (Settable) |
| Nature of Cooling | Air Cooled / Oil Cooled |
| Output Voltage Regulation | ±1% |
| Efficiency | >98% |
| Input Frequency | 50 Hz ± 3 Hz |
| Effect of Load Power Factor | Nil on output voltage |
| Speed of Correction | 30V/Sec |
| Servo Motor Drive/Type | AC Synchronous Stepper Motor & Opto-coupler based TRIAC drive |
| Display Type | LCD |
| Displayed Parameters | Input/Output Voltages, Hz, Amps |
| Protections | Under Voltage / Over Voltage cutoff, Overload & Short Circuit Protection |
| Control Design | Micro Controlled (DSP) based with O/P Sensing Feedback System |
| Operating Temperature | 0°C – 50°C |
| Manual Bypass | Through changeover switch above 5 KVA |
| Front Panel | Enter, Up/Down key |
| Waveform Distortion | Nil (same as input) |
| Nature of Winding | Copper Variacs |
| Enclosure | CRCA Mild Steel |
| Standard | As per I.S. 9815 |
| Oil Standard | As per I.S. 335 |
Note: Specifications are subject to change without notice due to continuous R&D. Customization is available on request.
